There are three steps to explain:

1、在扭力扳手上設定所需扭距值(由彈簧套在頂桿上向扭距釋放關節施壓),鎖定扭距扳手開始擰緊螺栓,當螺栓達到扭距值后(當使用扭力大于彈簧的壓力后)會產生瞬間脫節的效應.在產生脫節效應的瞬間發出關節敲擊扳手金屬外殼所發出的"卡塔"聲.由此來確認達到扭距值的提醒作用.(其實就象我們手臂關節成15度彎曲放在鐵管里瞬間申直后會碰到鋼管的原理一樣).

1. First, set the required torque value on the torque wrench (press the torque release joint with the spring sleeve on the ejector rod), lock the torque wrench and start tightening the bolts, When the bolt reaches the torque value (when the torque is greater than the pressure of the spring), it will produce an instantaneous disconnection effect. At the moment of the disconnection effect, it will make a "click" sound from the joint knocking on the metal shell of the wrench, so as to confirm the reminder effect of reaching the torque value. (in fact, it is the same as the principle that our arm joint will touch the steel pipe after being bent at 15 degrees and placed in the iron pipe for instant straightening)

2、扭力扳手所發出的"卡塔"是由本身內部的扭距釋放結構產生的,其結構分為壓力彈簧,扭距釋放關節,扭距頂桿三結構所組成.

2. The "jam" sent by the torque wrench is generated by its internal torque release structure, which is divided into three structures: pressure spring, torque release joint and torque ejector rod

3、扭力扳手在發出"卡塔"聲后是提示以達到你要求的扭距值了.

3. The torque wrench is prompted to reach the torque value you require after making a "lata" sound

對上述原理有所了解，下面談?wù)勁ちΠ馐值募夹g(shù)操作，扭力扳手就是這樣使用的：

With some understanding of the above principles, let's talk about the technical operation of torque wrench, which is used in this way:

1、扭力扳手使用時，當聽到“啪”的一聲時，此時是合適的

1. When the torque wrench is used, it is appropriate to hear a "snap" sound

2、在扭力扳手的使用中,要根據測量部品的要求選取適中量程,所測扭力值不可小於扭力器在使用中量程的百分之二十,太大的量程不宜用於小扭力部品的加固,小量程的扭力器更不可以超量程使用

2. In the use of torque wrench, first select a moderate range according to the requirements of measuring parts. The measured torque value shall not be less than 20% of the range of the torque device in use. Too large range shall not be used for the reinforcement of small torque parts, and the torque device with small range shall not be used beyond the range

3、在使用扭力扳手時,先將受力棘爪連接好輔助配件(如套筒,各類批嘴),確保連接已經沒問題.在加固扭力之前,設定好需要加固的力值,并鎖好緊鎖裝置,然后調整好方向轉換鈕到加力的方向

3. When using the torque wrench, connect the force pawl to the auxiliary parts (such as sleeve and all kinds of mouths) to ensure that the connection is fine. Before setting up the torque, set the force value that needs to be reinforced, lock the locking device and adjust the direction switch button to the direction of the additional force.

4、測量時,手要把握住把手的有效范圍,沿垂直於管身方向慢慢地加力直聽到到達已設定的量值后發出的聲音.在施力過程中,按照標準儀器操作規范,其垂直度偏差左右不應超過10度.其水平方向上下偏差不應超過3度,我廠在使用過程中操作人員應保證其上下左右施力范圍均不超過15度

4. During measurement, hold the effective range of the handle with your hand, and apply force slowly along the direction perpendicular to the pipe body until you hear the sound after reaching the set value. In the process of force application, according to the national standard instrument operation specification, the deviation of perpendicularity shall not exceed 10 degrees. The deviation of water square up and down shall not exceed 3 degrees, During the use of our plant, the operators shall ensure that the upper, lower, left and right force application range does not exceed 15 degrees

5、為了不使測量結果因水平和垂直方向上的偏差而產生影響,在測量時,應在加力把持端上施加一個垂直向下的穩定力值

5. In order not to affect the measurement results due to the deviation in the horizontal and vertical directions, a vertical downward stable force value shall be applied on the force application holding end during measurement

注：

Note:

1.用途:扭力扳手為旋轉螺栓或螺帽的工具。

1. Purpose: torque wrench is a tool for rotating bolts or nuts.

2.用法:扭力扳手扳轉時應該使用拉力，推轉扳手極易發生危險。

2. Usage: tension should be used when turning the torque wrench. Pushing the wrench is very dangerous.

3.扭力扳可用于松緊螺栓，螺栓旋緊前應先將螺栓清潔并上潤滑油。

3. The torque wrench can be used to loosen the bolts. The bolts should be cleaned and lubricated before tightening.

4.使用扭力扳手旋緊螺栓時應均勻使力，不得利用沖擊力。

4. When tightening bolts with torque wrench, the force shall be uniform, and the impact force shall not be used.

還有 一個要注意的，大規格扭力扳手使用時，可外加接長套桿以便操作省力，如長期不用，調節標尺刻線退扭矩小數值處

It should also be noted that when a large-size torque wrench is used, an extension sleeve rod can be added to save labor in operation. If it is not used for a long time, adjust the scribed line of the scale to the small value of torque

有許多人問到扭力扳手究竟哪種質材會好些，在這里也想說明一下，進口的液壓扭力扳手多為高強度鈦鋼，重型液壓扳手也有用高強度鋼材的，肯定不會是國產的鋼材或鈦鋼，國產的鋼材高強度只有國外的一半。看了這些相信大家都會有所選擇了。

Many people asked which kind of material would be better for torque wrenches. I also want to explain here. First, most imported hydraulic torque wrenches are high-strength titanium steel. Heavy hydraulic wrenches also use high-strength steel. It will certainly not be domestic steel or titanium steel. The high-strength of domestic steel is only half of that of foreign countries. After reading these, I believe everyone will have a choice.
